Gama de capacidad:
De 1000 a 8000 cfm (de 28,3 a 226,5 m3/min)
Punto de condensación de presión:
De -40 °F a -100 °F (de -40 °C a -70 °C) ISO Clase 1 a 2
Voltaje:
De 460 V/3 PH/60 Hz (400 V/3 PH/50 Hz)
Presión máxima de entrada:
150 psig (10,3 barg)
Temperatura máxima de entrada:
122 °F (50 °C)
Tipo desecante:
Alúmina activada



Características

  • High Quality Air: Proven high-performance desiccant technology delivers -40°C (-40°F) pressure dew point air for critical applications; pre-filter and after-filter protect desiccant and downstream air from oil contamination and particulates
  • Easy to Maintain: A low profile design and easy access to components simplifies installation and maintenance
  • Reliable Operation: High-strength desiccant along with durable valves and components provide extended life
  • Reduced Energy Use: Low pressure drop design saves on energy costs and provides an economical drying solution
  • Smart Control: Easy to use, advanced microprocessor helps to maintain dryer performance at optimum levels, while constantly monitoring functions and provides maintenance alerts as well as protection notifications



Especificaciones del módelo



Modelo Capacidad m3/min (scfm) Heater kW Blower kW Length x Width x Height mm (in) Weight kg (lb) Connection Air In/Out
HB150 4.2 (150) 3 0.75 840 (33) x 1,143 (45) x 1,676 (66) 476 (1,050) 1″ NPT
HB200 5.7 (200) 4.5 0.75 940 (37) x 1,245 (49) x 1,702 (67) 522 (1,150) 1 1/2″ NPT
HB250 7.1 (250) 6 1.1 970 (38) x 1,350 (53) x 1,727 (68) 635 (1,400) 1 1/2″ NPT
HB300 8.5 (300) 6 1.1 970 (38) x 1,350 (53) x 1,727 (68) 680 (1,500) 1 1/2″ NPT
HB400 11.3 (400) 9 1.5 1,220 (48) x 1,450 (57) x 2,108 (83) 862 (1,900) 2″ NPT
HB500 14.2 (500) 12 1.5 1,220 (48) x 1,450 (57) x 2,108 (83) 953 (2,100) 2″ NPT
HB600 17.0 (600) 12 3.7 1,500 (59) x 1,620 (64) x 2,235 (88) 1,270 (2,800) 3″ NPT
HB800 22.7 (800) 18 3.7 1,500 (59) x 1,620 (64) x 2,235 (88) 1,452 (3,200) 3″ NPT
HB1000 28.3 (1,000) 24 5.6 1,500 (59) x 1,980 (78) x 2,032 (80) 1,709 (3,767) 3″ NPT
HB1200 34.0 (1,200) 24 5.6 1,500 (59) x 1,980 (78) x 2,032 (80) 1,860 (4,100) 3″ NPT
HB1500 42.5 (1,500) 30 11.2 1,650 (65) x 2,490 (98) x 2,337 (92) 2,502 (5,515) 3″ NPT
HB1800 51.0 (1,800) 36 11.2 1,730 (68) x 2,490 (98) x 2,337 (92) 2,773 (6,113) 4″ FLG
HB2100 59.5 (2,100) 45 11.2 1,730 (68) x 2,490 (98) x 2,337 (92) 3,135 (6,911) 4″ FLG
HB3000 84.9 (3,000) 60 14.9 1,980 (78) x 3,050 (120) x 2,540 (100) 4,413 (9,730) 6″ FLG
HB4000 113.3 (4,000) 80 18.7 2,110 (83) x 3,200 (126) x 2,337 (92) 5,519 (12,167) 6″ FLG
HB5000 141.6 (5,000) 100 22.4 2,210 (87) x 3,500 (138) x 2,464 (97) 6,472 (14,720) 6″ FLG
HB6000 169.9 (6,000) 125 22.4 2,390 (94) x 3,810 (150) x 2,616 (103) 7,911 (17,440) 6″ FLG
HB8000 226.5 (8,000) 175 29.8 2,490 (98) x 4,270 (168) x 2,667 (105) 9,026 (19,900) 8″ FLG
